TECHNICAL DATA:
|
Mode of Operation |
?Maintained |
|
Input Voltage |
?120/277VAC 60HZ |
|
Battery |
?3.6V 2500mAh Nickel Cadmium Battery |
|
Lamp used |
one 21W,28W T5,32W T8 Fluorescent lamp.(Please Refer to Supplier) |
|
Operating Temperation |
?0??~50?? |
|
Charger |
?Solid-state Electronics Provide High Reliability with Trickle Charge-Facility. |
|
Indication |
?Red LED |
|
Backup time |
???90minutes |
|
Compliance |
?UL, cUL |
|
Protection |
?Low-Voltage Cut-Off to prevent Over-Discharge of Battery |
The JEB series Emergency Ballasts allow the same lighting fixture to be used for both normal and emergency operation. In the event of a power failure, the JEB switches to the emergency mode and operates the fluorescent lamps or PLC tubes for a minimum of 90 minutes. The unit contains a battery, charger and inverters IN A SINGLE PACKAGE. The EBAL can be mounted in the wireway or on the top of fixture. And is UL, cUL approval.
